With the Phoenix Psychrometric Calculator, you can accurately calculate dew point and specific humidity (grains of water per pound of air) without fumbling through awkward psychrometric charts. Simply set the temperature and relative humidity; the specific humidity and dew point temperature are displayed in their respective windows.

This moisture content information is crucial to the restoration professional in order to determine the drying strategy and monitor the drying process.

For an example of how easy it is to find moisture content information with the Phoenix Psychrometric Calculator, see the reverse side of this page.

Measures:

• Air Flow
• Temperature
• Relative Humidity
• Dew Point
• Wind Chill
• Heat Stress

• Provides accurate moisture content information in an easy-to-use tool
• Helps avoid common data input errors
• Accepts input data from 3% to 100% relative humidity
• Accepts temperature inputs from 20°F (-7°C) to 120°F (49°C)
• Temperature and dew point are listed in both Fahrenheit and Celsius

Spec Sheet

Multiple Purpose Hand Held Meter

The Phoenix Kestrel 3000 Multi-Meter—all the information you need from an instrument you can carry in your pocket!

The Kestrel 3000 Multi-Meter is a unique hand-held multi-purpose meter that is not only pocket sized but also user friendly. With its air flow operation mode options, the Kestrel 3000 allows you to calculate the current, maximum and average air flow, and has the added ability to display each one in different measuring methods (i.e., knots, meters per second, kilometers per hour, miles per hour, feet per minute and Beaufort). Temperature, wind chill, heat stress and dew point temperature can be displayed in both C° and F°. Relative humidity is expressed as a percentage.

The Kestrel 3000 measures air flow with a large diameter precision ultralight impeller which turns on sapphire bearings, providing excellent accuracy (+/- 3%) and the ability to measure the slightest breeze (0.3 M/S). The impeller and protective housing pop out without tools for easy and inexpensive replacement.

For temperature readings, the Kestrel uses an external thermistor for fast response and accuracy of +/- 4° F. The capacitive humidity sensor is factory calibrated to +/- 3% accuracy. Heat stress measurements are accurate to +/- 3% and dew point temperature to +/- 2°. Wind chill, heat stress and dew point temperature are automatically calculated.

The hard slip-on case protects the Kestrel 3000’s reflective LCD display, tactile rubber buttons, and large diameter impeller from damage. The user replaceable coin cell battery provides 300 hours of use. To insure long battery life the Kestrel also features an “auto shutdown” mode that turns your meter off 30 minutes after the last key is pressed. The Kestrel 3000 is covered by a full one-year warranty and is protected by US patent No. 5, 753,784.

The Kestrel 3000 Multi-Meter—all the information you need from an instrument you carry in your pocket!

Measures:

• Air Flow
• Temperature
• Relative Humidity
• Dew Point
• Wind Chill
• Heat Stress

• User replaceable CR2032 coin cell battery
• Hard slip-on case

Spec Sheet

The Premier Humidity Meter

The Phoenix HMI-41 Precision Thermo Hygrometer is the fastest and most accurate humidity meter in the industry. It provides a convenient and reliable way to spot check relative humidity, temperature, dew point, and grains per pound.

This instrument is the advanced version of the Phoenix HM-34, which has been widely used in the restoration industry and has established a reputation for accuracy and dependability. Manufactured by the Vaisala Company in Helsinki, Finland, the Phoenix HMI-41 meter will provide years of trouble-free service.

The Phoenix HMI-41 meter incorporates Vaisala’s next generation HUMICAP® Sensor, which is accurate, durable and resistant to dust and most chemical contaminants. Both the humidity and temperature sensors are housed in a plug-in probe. The MODE button allows the user to select from three LCD displays: (1) relative humidity on top and temperature below, (2) dew point on top and temperature below, and (3) temperature on top and grains per pound below. The HOLD button freezes the measurement until it has been noted or recorded.

When left idle for five minutes, the HMI-41 will automatically switch off unless the MODE or HOLD function has been activated. This automatic POWER-OFF function is adjustable and prevents accidental discharge of the HMI-41’s batteries.

Each Unit Includes:

• HMI-41 Indicator
• HMP-41 Probe
• 4 Type AA batteries

• Spec Sheet
• Instructions

The pocket-sized Phoenix HM-34 Thermo Hygrometer provides a fast and convenient way to accurately spotcheck relative humidity and temperature. The HM-34 has been widely used in the restoration industry for many years and has established a solid reputation for accuracy and dependability. Considered to be the best in the business because of its proven performance, the HM-34 has become the industry standard by which all other meters are now compared.

Manufactured by the Vaisala company in Helsinki, Finland, the Phoenix HM-34 meter will provide years of trouble-free service. The Phoenix HM-34 meter incorporates Vaisala’s next generation HUMICAP® Sensor, which is accurate, durable and insensitive to dust and most chemical contaminants. Both the humidity and temperature sensors are housed in an extendable probe that retracts back into the rugged plastic casing for storage, creating a compact and easy-to-carry device.

The HOLD button allows the user to retain a relative humidity (RH) or temperature (T) measurement until it has been noted or recorded. When left idle for three minutes, the HM-34 will automatically switch off unless the HOLD function has been activated. This automatic POWER-OFF function prevents the accidental discharge of the HM-34’s 9 volt battery.

Each Unit Includes:

• 9V battery
• Attached probe
• 0.2 um protective membrane filter
• Carrying case

• Lightweight, pocket-sized
• Extendable probe
• Automatic POWER-OFF
• Measures humidity and temperature
• Fast response

• Spec Sheet
• Manual

Effective and Efficient System For Creating a Grain Barrier

The Phoenix Quick Chamber, designed with the Restoration Professional in mind, is an easy way to create an effective drying chamber that will completely contain a water loss affected area within minutes. This containment can be accomplished practically anywhere in the structure (e.g., hallway, doorway, etc.) simply by sealing open thresholds and passageways. The Quick Chamber not only incorporates durability in its construction and installation, but flexibility in its application. It has been specifically designed to be installed by one person, so an effective drying chamber can be set up by an individual rather than a team.

Once installed, the Quick Chamber will restrict moisture transfer into and out of the water loss affected area. This will also stop secondary damage at the beginning of the job, and later enhance the dry-down by preventing moist air from migrating into your drying chamber. Don’t waste valuable dehumidifying capacity–minimize the area that you need to dry. By staying focused on just the affected area, you can free up the necessary equipment needed to move on to the next job.

Each step in the Water Loss Drying System is important, and the first step of creating a drying chamber is no exception. Every water restoration team should have a Phoenix Quick Chamber System in their truck.

Features

• QUICK set up
• Outstanding Phoenix reliability
• Versatile adjustment from 27″ out to 73″
• Lightweight rigid aluminum parts
• “L” feet positively lock plastic in place and will not rotate or slip out of position
• Spring clip retainers to hold plastic during set-up to maintain a tight seal


• One Quick Chamber System carrying case with dividers to keep Quick Chambers in great shape and room for a plastic sheet.
• Three Phoenix Quick Chambers, each adjustable from 27″ out to 48″ wall separation.
• One Extender bar, extending the range of any Quick Chamber to openings from 48″ to 73″.
